4G AI dash camera with WIFI, GPS Front+IR inside cam
P/N: SAT3

Specifications:

• CPU: MTK6753 Octa-core ARM® 1.3GHz Cortex-A53
• Operation system: Android 5.1 RAM1G and ROM8GB( this can be custom-made)
• GPS: external GPS antenna
• Camera Lens: Support front and inside cam recording ( AHD1080P+720P)
• Network Bands: “2G GSM B5/B3
• 3G WCDMA B1/B5 FDD-LTE B1/B3/B5 (B4 band is optional)”
• Front camera: GC2053（1080P）；4 glass 150° wide angle ；H.264 code；MIPI interface
• IR Inside camera: GC1064 (720P)4 glass+IR(850)；4 glass 135° wide angle MIPI interface
• IR night vision: Support Infrared light,there is 6pcs 850 led on the inside cam
• SOS: Support one-key click alarm
• Wi-Fi: 802.11ac/b/g/n 2.4G&5G, support Wi-Fi hotspot.
• Video format: TS
• Video compression: H.264
• G-Sensor: 3-axis G-Sensor
• USB: MINI USB 2.0, support OTG function
• Storage: TF card, support Maximum 128G card with class 10 or above
• Software upgrade: Upgrade by TF card, OTA online upgrade.
• MIC: Build in MIC-Phone Noise Reduction microphone
• Speaker: Built-in high-fidelity  4Ω2W speaker
• Key buttons: Reset and power button
• Working Temperature: -20~+70°C
• Power supply: fit 9-16V power supply
• 8ch 1080P HD video input
• Suppot HDD&SD storage
• Support WIFI，WIFI AP，3G，4G
• Support ADAS, DSM
• Intercom, PTT
• Built-in G-sensor
• Aviation interface
