Single Phase Energy Meter
P/N: SA-SPM
$ 60.00
Specifications:
- Accuracy: Level 1
- Current: 2.5(10)A, 5(20)A, 10(40)A, 15(60)A, 20(80)A, 30(100)A
- Rated voltage: 220V
- Interface mode: pulse
- Normal working voltage: 0.9Un～1Un
- Limit working voltage: 0.8Un～15Un
- Voltage circuit power consumption: ≤2W or 5VA
- Current circuit power consumption: ≤1VA
- Voltage of battery for RTC: 3.6VDC(1200mAh)
- Backup battery: 6.0VDC (1500mAh)
- Clock accuracy: ≤0.5s( in 24 hours)
- Data storing time after power outage: 2.5 years
- Normal working temperature: -25℃~+60℃
- Limit working temperature: 25℃~+80℃
- Storage and transport humidity: ≤95%
- Display Type: LCD
- Communication baud start rate: 300bps
- Communication baud Protocol rate: 9600bps
